Waveform Generator


Available on Moku:Go, Moku:Lab, and Moku:Pro hardware

Liquid Instruments

Waveform Generator

The Waveform Generator enables you to generate five types of built-in independent waveforms: sine, square, ramp, pulsed or DC. Modulate phase, frequency, or amplitude, or generate triggered bursts or sweeps from internal or external sources.

Below is the Waveform Generator’s user interface showcasing some of the key features explained below:

Key Features of the Waveform Generator:

Advanced modulation options

Frequency Modulation (FM), Amplitude Modulation (AM), and Phase Modulation (PM) are available with the Waveform Generator. These can be standardly modulated by an internally generated sinewave, through an external input, or through cross-channel modulation.

Cross-channel modulation enables the output of one channel to modulate another channel. For example, an FM square waveform can be used to modulate a sine waveform creating a cross-channel modulated output signal.


Waveform Types:

The five predefined waveforms are: Sine, Square, Ramp, Pulse and DC.

The Sine, Square, and Ramp waveforms can be configured for frequency, amplitude, offset, and phase. You can also change the ramp waves’ symmetry and the pulse waves’ pulse width and edge time.


Enable/Disable Outputs:

The outputs can be enabled or disabled through a tap of a button.


API Support

Easily integrate Moku into your current setup with Python, MATLAB, and LabVIEW.



  • Signal simulation
  • System synchronisation
  • Laser scanning microscopy
  • Circuit design and characterisation
  • Clock source
  • DAC/Op-amp characterisation

The Waveform Generator runs on Moku:Go, Moku:Lab and Moku:Pro. You can compare the platform specifications below:

Waveform Generator
Waveform Generator
Waveform Generator
Channel Count
2 input / 2 output 2 input / 2 output 4 input / 4 output
Frequency Range
DC to 20 MHz DC to 250 MHz DC to 500 MHz
Output Voltage
± 5 V into 1 MΩ ± 1 V into 50 Ω Up to ± 5 V into 50 Ω
Sampling Rate
125 MSa/s 1 GSa/s 1 GSa/s
12 bits 16 bits 16 bits
Deployable in Multi-instrument Mode?
Yes N/A Yes
Software & Utilities
macOS App
Windows App
API support for Python, MATLAB, and LabVIEW
iPadOS App
Windows App
API support for Python, MATLAB, and LabVIEW
iOS App
API support for Python and MATLAB
Waveform Generator Datasheet - Moku:Go
Waveform Generator Datasheet - Moku:Lab
Waveform Generator Datasheet - Moku:Pro
Waveform Generator User Manual- Moku:Go
Waveform Generator User Manual- Moku:Lab
Waveform Generator User Manual- Moku:Pro
