10 & 20 Series

There are 7 different products in the 10 & 20 series, all varying with different wavelength ranges and aperture diameters. Please find all the variations and their specifications below, or contact us to find out more about our products.

The 10 and 20 series of OPM heads give average power and single shot energy measurement for high peak power lasers.

Three different absorber materials are used to cover different wavelength bands. Different types of glasses and ceramics are used to cover the UV-C range (190 – 250 nm), the UV-A (250 – 400 nm), and the VIS-NIR (BB absorber from 400 nm to 3 µm). These absorbers can withstand peak powers of 100 GW/cm² and energy densities up to 30 J /cm².

Readout Units & Calibration

These detector heads are fitted with the IIS (intelligent identification system EPROM) housed in the DB-15 connector. This interfaces directly with the Plus-USB, 4π, or PC-Link power meter readout units.

Calibration is offered as standard at 1064 nm or 10.6 µm at a range of power levels. Addition calibration wavelengths are also available on request. These are 355 nm, 532 nm, 632 nm and 908 nm.

Prices include one power or energy calibration certificate at your chosen wavelength. The calibration may be requested as power, energy, or power and energy. Please specify your wavelength and P, E or P+E when ordering.

Code: 10-BB-D12-L 10-BB-D25 10-UVA-D25 10-UVC-D25 20-BB-D40 20-UVA-D40 20-UVC-D40
Aperture Diameter: 12mm 25mm 25mm 25mm 40mm 40mm 40mm
Wavelength Range: 400 – 2100nm 400 – 5200nm 250 – 400nm 190 – 250nm 400 – 5200nm 250 – 400nm 190 – 250nm
Max Average Power: 10000mW
Series: 10-20
Datasheet
