790 nm VersaChrome Edge™ tunable shortpass filter

Semrock Logo

VersaChrome filters do what no thin-film filter has done before – offer tunability over a very wide range of wavelengths by adjusting the angle of incidence with essentially no change in spectral performance. They combine the spectral characteristics and two-dimensional imaging performance of a thin-film filter with the wavelength-tuning flexibility of a diffraction grating.

VersaChrome Edge tunable filters unlock virtually unlimited spectral flexibility for fluorescence microscopy and hyperspectral imaging, as well as for spectroscopy applications. By utilizing a combination of VersaChrome Edge tunable long-wave pass and short-wave pass filters, a bandpass filter as narrow as sub 5nm FWHM or as wide as 12% of the center wavelength throughout the visible and near-infrared wavelength ranges can be created. Semrock’s patented tunable thin-film filters can’t be found anywhere else in the market.

Visit our VersaChrome Edge™ tunable filters page for additional information.

Note on spectral plots:
In the past, each shipment has included a spectral plot for every filter and every lot code in the shipment. In an effort to be more eco-friendly, we will no longer be including these plots with each shipment. If you require spectral plot data, please see here for more information.

Optical Specifications
Transmission BandTavg > 93% over 89 nm
Transmission Band, @ 60 degTavg > 90% over 80
Edge Wavelength, @ 0 degMinimum 790 nm
Edge Wavelength, @ 60 degMaximum 704 nm
Blocking BandODavg > 6 (1.02*Edge Wavelength 0deg) – 907 nm
Blocking Band, @ 60 degODavg > 6 (1.025*Edge Wavelength 60deg) – 907
Cuton Transition Width2.5% (from transmission to blocking)
Cuton Transition Width, @ 60 deg3% (from transmission to blocking)


General Specifications
Angle of Incidence0 – 60 °
Cone Half-angle0 °
Filter Effective Index1.68 Understanding 'Effective Index of Refraction' neff
Optical Damage RatingNot tested


Physical Specifications (for standard parts - please contact us for custom sizes)
Mounted / UnmountedUnmounted
ShapeRectangular
Size25.2 x 35.6 x 2.0 mm
Transverse Dimensions, LxW25.2 mm x 35.6 mm
Transverse Tolerance, Mounted± 0.1 mm
Filter Thickness, Unmounted2.0 mm
Filter Thickness Tolerance, Unmounted± 0.1 mm
Clear Aperture≥ 80% (elliptical)
Surface Quality (Scratch-Dig)60-40
Substrate Thickness2.0 mm
Substrate TypeLow-autofluorescence optical quality glass
OrientationReflective surface marked with part number – Orient in direction of incoming light


TSP01-790-25x36

  • Size: 25.2 x 35.6 x 2.0 mm

Transmission
