709/167 nm BrightLine® Full Spectrum Blocking single-band bandpass filter

Semrock Logo

BrightLine® Full Spectrum Blocking single-band bandpass filter has been optimized to provide extended blocking down to UV wavelenghts (250nm) and up to the near infrared (NIR) and paired with a combination of VersaChrome Edge™ tunable long-wave-pass (TLP) and tunable short-wave-pass (TSP) filters to custom bandpass filters as narrow as sub 5 nm FWHM or as wide as 12% of the center wavelength throughout the visible and near-infrared wavelength range.

Note on spectral plots:
In the past, each shipment has included a spectral plot for every filter and every lot code in the shipment. In an effort to be more eco-friendly, we will no longer be including these plots with each shipment. If you require spectral plot data, please see here for more information.

Optical Specifications
Transmission BandTavg > 93% 625 – 792 nm
Transmission Wavelength709 nm
Transmission Wavelength Range625.5 - 792.5 nm
FWHM Bandwidth172.3 nm
Blocking BandODavg > 4 250 – 350 nm
ODavg > 6 350 – 613 nm
ODavg > 6 808 – 1200 nm


General Specifications
Angle of Incidence0 ± 5 °
Cone Half-angle7 °
Filter Effective Index1.90 Understanding 'Effective Index of Refraction' neff
Optical Damage RatingTesting has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm²) for over 500 hrs.


Physical Specifications (for standard parts - please contact us for custom sizes)
Mounted / UnmountedMounted
ShapeRound
Size25 x 3.5 mm
Transverse Dimensions, Diameter25 mm
Transverse Tolerance, Mounted+ 0.0 / - 0.1 mm
Filter Thickness, Mounted3.5 mm
Filter Thickness Tolerance, Mounted± 0.1 mm
Clear Aperture≥ 22 mm
Surface Quality (Scratch-Dig)60-40
Substrate Thickness2.0 mm
Substrate TypeLow-autofluorescence optical quality glass
OrientationArrow on ring indicates preferred direction of propagation of light


FF01-709/167-25

  • Size: 25 x 3.5 mm

Transmission

Loading chart data...

Optical Density

Loading chart data...

Semrock Spectral Plot Info
FF01-709_167_Spectrum
