468/553 nm BrightLine® dual-band bandpass filter

Semrock Logo

Individual multiband fluorescence bandpass filters that utilize Semrock’s patented single-substrate construction. These filters have extremely high transmission, steep and well-defined edges, and outstanding blocking between the passbands. All thin-film, hard-coated construction for unsurpassed performance and reliability.

Note on spectral plots:
In the past, each shipment has included a spectral plot for every filter and every lot code in the shipment. In an effort to be more eco-friendly, we will no longer be including these plots with each shipment. If you require spectral plot data, please see here for more information.

Optical Specifications
Transmission BandBand 1: Tavg > 90% 451 – 485 nm
Band 2: Tavg > 90% 541 – 565 nm
Transmission WavelengthBand 1: 468 nm
Band 2: 553 nm
Transmission Wavelength Range541 - 565 nm
FWHM BandwidthBand 2: 30.3 nm
Band 1: 40 nm
Blocking BandODavg > 4 700 – 850 nm
ODavg > 6 275 – 440 nm
ODavg > 6 495 – 530 nm
ODavg > 6 577 – 700 nm


General Specifications
Angle of Incidence0 ± 5 °
Cone Half-angle7 °
Filter Effective Index1.93 Understanding 'Effective Index of Refraction' neff
Optical Damage RatingTesting has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm²) for over 500 hrs.


Physical Specifications (for standard parts - please contact us for custom sizes)
ShapeRound
Size21.8 x 3.5 mm
25 x 5.0 mm
Transverse Dimensions, Diameter25 mm
Transverse Tolerance, Mounted+ 0.0 / - 0.1 mm
Filter Thickness, Mounted5.0 mm
Filter Thickness Tolerance, Mounted± 0.1 mm
Clear Aperture≥ 21 mm
Surface Quality (Scratch-Dig)60-40
Substrate Thickness3.5 mm
Substrate TypeLow-autofluorescence optical quality glass
OrientationArrow on ring indicates preferred direction of propagation of light


FF01-468/553-21.8-D

  • Unmounted
  • Size: 21.8 x 3.5 mm

FF01-468/553-25

  • Mounted
  • Size: 25 x 5.0 mm

Transmission

Loading chart data...

Optical Density

Loading chart data...

Semrock Spectral Plot Info
FF01-468_553_spectrum
