| Wavelength (nm) | Optical Density (OD) | Operating Mode / Tested Protection Level |
|---|---|---|
| 180 – 315 | (OD10+) | D LB10 + IR LB4 + M LB6Y |
| >315 – 385 | (OD8+) | D LB6 + IRM LB8 |
| >385 – 400 | (OD4+) | DIRM LB4 |
| 660 – <740 | (OD1+) | DIRM LB1 |
| 880 – <946 | (OD5+) | DIRM LB5 |
| 946 – <1030 | (OD6+) | DIRM LB6 |
| 1030 – <1400 | (OD7+) | D LB6 + IRM LB7 |
| >5250 – 14000 | (OD4+) | D LB3 + I LB4 + R LB3Y |
| Component | Specification |
|---|---|
| Coating | Front side anti-scratch / rear side anti-fog |
| Filter | P1P22 |
| Filter Colour | Blue grey |
| Filter Material | Plastic |
| Filter Technology | Absorption filter |
| Filter Thickness | ca. 2mm |
| Frame | FS1 |
| Properties | Lightweight, M-protection rating |
| Protection Class / Norm | EN 166, EN 169, EN 207 full protection, EN 208 Alignment protection |
| Protection Range | Infrared, near infrared, ultraviolet, visible |
| VLT (approx.) | 12% |
| Visual Brightness | Sufficient |
| Colour Recognition | Excellent |
