Individual fluorescence bandpass filters that have been optimized for use in a variety of fluorescence instruments. Pair this filter with other Nanopede filters to step through the spectrum in 20 nm Full-Width, Half Max (FWHM) steps. This value approach to filter design provides essential filter performance for detector-based applications.
This filter family is designed for scattered light and point detection applications only, for imaging applications, consider our BrightLine filters.
| Optical Specifications | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Transmission Band | Tavg > 93% 573 – 587 nm | Laser Wavelength | 405 nm 445 nm 488 nm 532 nm 633 nm |
Transmission Wavelength | 580 nm | FWHM Bandwidth | 20 nm | Blocking Band | ODavg > 5 330 – 564 nm OD > 5 405 nm OD > 5 445 nm OD > 5 488 nm OD > 5 532 nm ODavg > 5 596 – 900 nm OD > 5 633 nm |
| General Specifications | |||||
|---|---|---|---|---|---|
| Angle of Incidence | 0 ± 5 ° | Cone Half-angle | 7 ° | Optical Damage Rating | Testing has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm²) for over 500 hrs. |
| Physical Specifications (for standard parts – please contact us for custom sizes) | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Transverse Dimensions, Diameter | 12.5 mm | Filter Thickness, Mounted | 3.5 mm | Filter Thickness Tolerance, Mounted | ± 0.1 mm | Filter Thickness, Unmounted | 2.0 mm | Filter Thickness Tolerance, Unmounted | ± 0.1 mm | Clear Aperture | ≥ 10 mm | Surface Quality (Scratch-Dig) | 80-50 | Orientation | Arrow on ring is preferred direction of propagation of light |
