350 – 700 nm Semrock® General Purpose Mirror

Semrock Logo

Semrock’s General Purpose Mirrors offer high reflectivity with an ‘Imaging flat’ reflection.



Note on spectral plots:
In the past, each shipment has included a spectral plot for every filter and every lot code in the shipment. In an effort to be more eco-friendly, we will no longer be including these plots with each shipment. If you require spectral plot data, please see here for more information.





Angle of Incidence

45.0 ± 1.5 °

Clear Aperture

≥ 80% (elliptical)

Flatness / RWE Classification

Image-splitting

Optical Damage Rating

Testing has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm2) for over 500 hrs.

Product Type

General Purpose Mirror

Reflected Wavefront Error

< 2λ P-V RWE @ 632.8

Reflection Band

R > 98% 350 – 700 nm

Reflection Band, p-pol

R > 96% 350 – 700 nm

Reflection Band, s-pol

R > 99.5% 350 – 700 nm

Semrock Filter Family

Semrock® General Purpose Mirrors

Size

25.2 x 35.6 x 1.1 mm

Substrate Type

low-autofluorescence optical quality glass

Surface Quality (Scratch-Dig)

60-40

Transverse Dimensions, LxW

25.2 mm x 35.6 mm

Transverse Tolerance, Mounted

± 0.1 mm

Semrock Spectral Plot Info
MGP01-350-700_Spectrum
