785 nm EdgeBasic™ best-value short-pass edge filter

Semrock Logo

EdgeBasic filters offer an ideal combination of performance and value for applications including Raman spectroscopy and fluorescence imaging and measurements. They offer exceptional laser-line blocking and high transmission for Raman applications that do not require measuring the smallest possible Raman shifts and when cost is an issue.

Note on spectral plots:
In the past, each shipment has included a spectral plot for every filter and every lot code in the shipment. In an effort to be more eco-friendly, we will no longer be including these plots with each shipment. If you require spectral plot data, please see here for more information.

Optical Specifications
Transmission BandTavg > 80% 350 – 400 nm
Tavg > 93% 400 – 758.2 nm
Laser Wavelength785 nm
Laser Wavelength, high790 nm
Laser Wavelength, low780 nm
Edge Wavelength765.5 nm
Blocking BandODabs > 6 780.0 – 948.0 nm
ODavg > 3 948 – 1200 nm
Transition Width19.5 nm
313 cm-1
Edge Steepness1.5%
11.7 nm
189.5 cm-1


General Specifications
Angle of Incidence0 ± 2 °
Cone Half-angle5 °
Filter Effective Index1.73 Understanding 'Effective Index of Refraction' neff
Optical Damage RatingNot tested


Physical Specifications (for standard parts - please contact us for custom sizes)
Mounted / UnmountedMounted
ShapeRound
Size25 x 3.5 mm
Transverse Dimensions, Diameter25 mm
Transverse Tolerance, Mounted+ 0.0 / - 0.1 mm
Filter Thickness, Mounted3.5 mm
Filter Thickness Tolerance, Mounted± 0.1 mm
Clear Aperture≥ 22 mm
Surface Quality (Scratch-Dig)60-40
Substrate Thickness2.0 mm
Substrate TypeLow-autofluorescence optical quality glass
OrientationArrow on ring indicates preferred direction of propagation of light


BSP01-785R-25

  • Size: 25 x 3.5 mm

Transmission

Loading chart data...

Optical Density

Loading chart data...

Semrock Spectral Plot Info
BSP01-785R_Spectrum
