684/40 Avant™ Bandpass Filter
684/40 Avant™ Bandpass Filter - Image 2

Related products

684/40 Avant™ Bandpass Filter

Semrock Logo
Add to Quote
Ask the Expert

For optimal filter set performance, pair this emitter with AF01-633/40 and AF659-Di01, which have been optimized for Cy5™, Alexa Fluor 647, and other key fluorophores. Precise edge placement of the steep spectral edges combined with deep complementary blocking maximize fluorophore performance compared to standard exciter and emitter pairs.

Optical Specifications
Transmission BandTavg > 93% 664 – 704 nm
Transmission Wavelength684 nm
FWHM Bandwidth44.7 nm
Blocking BandODavg > 5 200 – 275 nm (Design specification – measurements are noise-floor limited).
ODavg > 6 275 – 599 nm
ODavg > 10 599 – 653 nm (Design specification – measurements are noise-floor limited).
OD > 3.5 658.5 nm
ODavg > 6 720 – 850 nm
ODavg > 2 850 – 1100 nm


General Specifications
Angle of Incidence0 ± 5 °
Cone Half-angle7 °
Optical Damage RatingTesting has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm²) for over 500 hrs.


Physical Specifications (for standard parts - please contact us for custom sizes)
Filter Thickness, Mounted3.5 mm
Filter Thickness Tolerance, Mounted± 0.1 mm
Filter Thickness, Unmounted2.0 mm
Filter Thickness Tolerance, Unmounted± 0.1 mm
Clear Aperture≥ 22 mm
Surface Quality (Scratch-Dig)60-40
OrientationArrow on ring is preferred direction of propagation of light



Transmission

Loading chart data...

Optical Density

Loading chart data...

Semrock Spectral Plot Info
af01-684_40_measured
