585/29 Avant™ Bandpass Filter

Semrock Logo

For optimal filter set performance, pair this exciter with AF01-626/35 and AF604-Di01, which have been optimized for Texas Red, Alexa Fluor 594, and other key fluorophores when used as a filter set. Precise edge placement of the steep spectral edges combined with deep complementary blocking maximize fluorophore performance compared to standard exciter and emitter pairs.

Optical Specifications
Transmission BandTavg > 93% 570 ­– 599 nm
Transmission Wavelength585 nm
Blocking BandODavg > 5 275 – 340 nm
ODavg > 10 609 –­ 659 nm (Design specification – measurements are noise-floor limited)
ODavg > 6 659 – 850 nm


General Specifications
Angle of Incidence0 ± 5 °


Physical Specifications (for standard parts - please contact us for custom sizes)
Transverse Dimensions, Diameter25 mm
Filter Thickness, Mounted5 mm
Filter Thickness Tolerance, Mounted± 0.1 mm
Filter Thickness, Unmounted2.0 mm
Filter Thickness Tolerance, Unmounted± 0.1 mm
Clear Aperture≥ 21 mm
Surface Quality (Scratch-Dig)60-40



Transmission

Loading chart data...

Optical Density

Loading chart data...

Semrock Spectral Plot Info
AF01-585_29Measured
